Product Details

Small Granule Spice Vertical Metal Detection Machine Raw Material Metal Detector

The overall structure design of the vertical granule metal detection machine is simple and firm, with high detection sensitivity and stable performance. The digital vertical metal detector machine can adjust and compensate for internal parameters based on the size of the product effect, thereby achieving safe product passing and detecting metal impurities.  Any OEM and customer design orders are welcome! If you are interested in our products, please feel free to contact us.

Vertical granule metal detection machine photos

Materials: detector grade 304 stainless steel, frame grade 201 stainless steel, PVC/PU white tape.

Belt length (mm): 1600mm.

The height of the conveyor from the belt to the ground is adjustable from 650mm to 100mm feet, including movable wheels.

Alarm system: buzzer/warning light.

Flow rate: fixed at 25 m/min or variable from 10 to 40 m/min.

Flow direction: From left to right or opposite (facing the control panel).

Operating system language: English/Chinese.

Power supply: AC110V/220V, 50/60Hz, power: 90/120/200W.

This vertical granule metal detection machine is exclusively customized according to customer requirements and may not meet your requirements. Our company's digital metal testing machines are available in stock from the factory and offer non-standard customized equipment. We offer a variety of metal testing machine solutions for free. Please feel free to contact us at any time.

The vertical granule metal detection machine has a wide range of applications and can be used in powder and granular products from multiple industries and fields, such as the food industry, pharmaceutical industry, cosmetics industry, plastic and rubber industry, textile industry, and other industries to determine whether there are metal fragments or impurities in raw materials, semi-finished products, and finished products.

1. Vertical granule metal detection machine can be used to detect iron, copper, aluminum, and stainless steel metals mixed in non-metallic products, and the digital differentiation display of iron and non-iron signals;

2. Equipped with belt correction design, it is not easy to deviate during long-term operation.

3. Single and double coil detection can be used alone or in combination, with Chinese and English menus.

4. Adopting digital DSP programming design, LCD display screen with thin film switch touch control panel

5. Can automatically set learning to obtain applicable detection performance, and can store memory for 100 products.

6. Equipped with automatic learning function for product effects, product effect filtering, and the ability to detect stainless steel and non-ferrous metal copper test pieces even after small aluminum foil packaging.

7. The entire machine frame adopts stainless steel material laser cutting welding and wire drawing technology, food white PVC or PU belt, 304 stainless steel pipe or non-metallic drum optional

8. Vertical granule metal detection machine has seismic resistance and is less likely to cause false alarms due to collisions and knocking on the machine.

Shanghai Shigan Industrial Co., Ltd. is a professional enterprise engaged in international trade business. We operate checkweighers, metal detection machines, etc. Our company has a strict quality control system. Some of our machines have passed CE certification. We can provide technical support, pre-sales, and after-sales services to customers at any time, making us a popular supplier both domestically and internationally. At present, our sales network has covered Europe, America, Southeast Asia, the Middle East, Africa and other places.

1. Before packaged, the machines will be tested strictly to guarantee the stability and high accuracy.
2. After tested, the machines will be wrapped with plastic sheet and carefully packed in wooden cases.

1. Equipment installation and debugging: The company provides detailed operation manuals and free operation training to enable customers to proficiently master the usage methods of the equipment.

2. Technical Support: The company provides 7x24 hours of technical support, and customers can contact engineers at any time to solve any problems they encounter during use.

3. Accessories supply: The company provides original accessories to ensure the quality and stability of the accessories.

4. Quality assurance: The company is responsible for the products sold, ensuring that the quality and performance of the equipment meet industry standards.

5. One year warranty and lifelong maintenance
