Product Details

SHIGAN Continuous Quantitative Capsule Tablet Sample Checkweigher Machine

The quantitative capsule tablet sample checkweigher machine is a precision weighing device specially used for weight detection of capsule dosage form products in the pharmaceutical industry. It is used to sample and check capsules in the production line to ensure that the weight of each capsule meets the specified standard. The automatic capsule tablet sample checkweigher adopts a stable mechanical structure and high-quality sensors to ensure the accuracy of the weighing results. To know more about us, please you do not hesitate to contact us or visit our factory.

Quantitative capsule tablet sample checkweigher picture

Type SG-DJ10

Weighing Range 20-2000mg

Limited of product L: 100 W: 100 H: 2-150mm

Accuracy ±1mg Depends on product

Division Scale  1mg

Each Channel Speed 100 pcs/min

Machine Weight 80kg

Power Supply AC -220V ±10% 50HZ

Power 100W

Main Material SU304 stainless steel

Our company can provide customized automated mechanical equipment such as unqualified automatic rejection and quantitative capsule tablet sample checkweigher according to the user's production and application environment requirements.

1. When the accuracy is 2.0mg, the maximum speed of each channel is 120 tablets/minute.
2. 1 or 2 check weight display windows.
3. Calibration of 1 or 2 channels can be completed within 1 minute.
4. The check weight results of all channels are displayed in a bar graph.
5. The weight curve and standard deviation of the first 20 tablets, as well as the weight of each tablet sampled in the batch and its average value can be displayed.
6. USB and printer interface, in addition to the USB disk export function, is also equipped with a high-speed printer. The operator can sign and confirm on the paper record and keep it permanently. It is a method of quality traceability and cannot be changed.
7. 10-inch touch screen, user-friendly interface, fast response speed, large memory, high reliability.
8. HMI interface: Chinese and English.

SHIGAN Continuous Quantitative Capsule Tablet Sample Checkweigher Machine

SHIGAN Continuous Quantitative Capsule Tablet Sample Checkweigher Machine

Free export fumigation plywood box with quick connection design, easy to open and reuse;

Internal plastic film packaging can protect goods from salt, wind, or damage;

Training services:

We will train your engineer to install our weigher.You can send your engineer to our factory or we dispatch our engineer to your company.We will introduce your engineer how to install the weigher and how to fix problem.

Trouble shooting service:

Some times if you can not fix the problem in you contry,we will seed our engineer there if you need us to support.Of course,you need to afford the round trip flight ticket and accommodation fee.

Spare parts relpacement:

For spare parts support: For machine in guarantee period,if spare part broken,we will send you the parts free and we will pay the express fee,And please send us the spare part back,when machine is out of guarantee period,we will provide you the spare parts in cost price.
