Product Details

High Precision Food Weight Sorting Grading Machine Multistage Checkweigher

The food multistage weight sorting grading machine adopts high-tech and single-chip high-speed control to detect whether the product weight is consistent with the interval setting target, and the sorting device automatically selects the product. This high precision multistage sorting checkweigher is built-in with the world's advanced digital weighing unit, which can achieve high-speed, accurate and stable measurement. It is widely used in the integrated automation production and packaging industry. You are welcome to contact us at any time for quotation.

Food multistage weight sorting grading machine pictures

1. The weighing processor of the multi-level sorting scale is independently developed by technicians, with good performance and strong anti-interference ability

2. 100 preset formulas, simple switching method

3. Data can be automatically stored, and reports or curves can be generated

4. Equipped with high-precision and high-speed sensors

5. Sorting speed is up to 120 times/minute

6. Weighing processing range 100~3000g

7. Detection accuracy starts from ±1.0g

8. Sorting level 2~24 (customizable according to customer needs)

9. Hierarchical user management software, can be connected to the mes system

10. Friendly human-machine interface and simple operation

11. The whole machine supports customized waterproof, explosion-proof and dustproof

12. Open communication interface RS485/232 RJ45

13. Zero tracking can be set manually or automatically

14. The upstream and downstream of the production line can be equipped with metal detection, automatic labeling, and automatic packaging.

15. Easy installation and maintenance, the conveyor belt is easy to disassemble and clean

Type SG-D300

Weighing Range 5-3000g

Limited of product L: 350 W:300 H: 3-200mm

Accuracy ±0.3g-0.5g Depends on product

Division Scale 0.1g

Belt Speed 0- 50 m/min

Max Speed  60 pcs/min

Belt Width 300mm

Machine Weight 60kg+150kg

Power Supply AC 220V 50HZ

Power 1000W

Main Material SU304 stainless steel

High Precision Food Weight Sorting Grading Machine Multistage Checkweigher

1st step: Customer has showed his special requirements.

2nd step: We try to understand the conception and pattern from customer with simple draft or refer picture.

3rd step: Making the conceptive CAD drawing based on communication and understanding.

4th step: Making the detail and 3D drawing agter fixed the design and other details.

5th step: Offer the quotation after confirm the design,material and surface treament.

6th step: Making the sample for approval.

7th step: Testing installation after demo mock up.

8th step: Big production delivery and service after sales.

1. Aquatic products: fish, sea cucumber, abalone, lobster, oyster, crab, shellfish, etc.

2. Poultry: chicken legs, chicken wings, duck legs, duck wings, white-striped duck, various meat products, ham sausage

3. Agricultural and sideline products: fruits, vegetables

4. Medicinal materials: Cordyceps sinensis, Panax notoginseng, ginseng and other precious medicinal materials5. Industrial products, auto parts, precious metals

High Precision Food Weight Sorting Grading Machine Multistage Checkweigher

Packing Detail:

Each Machine with plastic film package first, then placed in a wooden case, wooden case with a foam filling.

We loaded the truck with heavy trucks for loading the cargo to the harbor terminal.At the dock we pack the goods in containers and ship them abroad.

Delivery Detail :

Shipped in 25 days after payment

✔ Security:We are suppliers,Direct sales,More guarantee product quality, after-sales service and so on

✔ The professional services:Years of good faith service,Solve technical problems in various ways,After-sale no Worries

✔ The perfect process :Strict bill of lading, the specification of docking,Strict quality control process,Strict debugging before out of the factory

✔ Powerful:Strong design team, accept orders and deliver quickly
