Product Details

1kg Coffee Beans Large Bag Checkweigher with Medium Speed Weight Checker

The coffee beans bag checkweigher can check the weight of packaged products online, whether they are overweight or overweight, to ensure that the weight of the product meets the standards. A large bag checkweigher with medium speed is an automatic device used in automatic packaging production lines to check the weight of products. It can check whether the weight of products meets the standard weight we set during continuous operation. In addition, the weighing scale can automatically reject unqualified products. Can feel free to contact us for more details, and you will be warmly welcome to visit us.

Coffee beans bag checkweigher photos

Type SG-300U

Weighing Range 5-3000g

Limited of product L: 350 W:300 H: up3mm

Accuracy ±0.3g-0.5g Depends on product

Division Scale 0.1g

Belt Speed 0- 60 m/min

Max Speed 80 pcs/min

Belt Width 300mm

Machine Weight 85kg

Power Supply AC -220V 50HZ

Power 200W

Main Material SU304 stainless steel

1kg Coffee Beans Large Bag Checkweigher with Medium Speed Weight Checker

1. Strong practicality: 10 inch high color, high-resolution human-machine interface, easy and user-friendly operation;

2. High stability: 24-hour high-speed and high-precision operation. Advanced and rigorous design concepts greatly reduce mechanical system failures and improve production efficiency;

3. High speed and high precision: using high-speed and high-precision German HBM sensors

4. Material accessories: The entire body structure is made of 304 stainless steel, which is anti-theft, corrosion-resistant, and has a long service life.

5. The weight inspection data comes standard with a USB interface and can be exported as an EXCEL spreadsheet

6. Easy to maintain: Unique conveyor belt structure design, modular design, easy disassembly and cleaning, protection level IP65.

7. Easy to connect: Using a DC brushless motor, it is more stable and has a smaller and more delicate structure. Suitable for greater speed requirements.

8. Easy to switch: can store 99 product formulas, and change product parameters with just one click.

Purpose: This automatic checkweighermachine is suitable for checking whether the weight of a single item is qualified, and is widely used in industries such as electronics, food, medicine, beverages, healthcare, and chemical engineering.

The products on this page are standard models, and the parameters are for reference only. We can customize them according to your needs. Generally speaking, customers need to provide the following parameters to determine the specifications of the large bag checkweigher.

[Product size range] ________________mm

[Product weight range] ________________ g

[Detection speed] __________________ P/min

[Detection accuracy] __________________

[Facing the direction of screen transport] left to right, right to left

[Belt to ground height] __________________mm

[Operating Environment]_________________________________

The above information can determine the specifications and models of the online weighing scale

We are Shanghai Shigan Industrial Co., Ltd., an instrument expert headquartered in Shanghai, China. Since 2010, we have been specializing in the production of assembly line automatic checkweigher and digital metal detector machinery. In its more than 15 year history, our products have sold well in the European, American, and Southeast Asian markets, with over 90 countries, particularly favored by European and American countries.

Free export fumigation plywood box with quick connection design, easy to open and reuse;

Internal plastic film packaging can protect goods from salt, wind, or damage;

Our transportation methods include diversification, and we can choose transportation methods based on customer needs, including sea, land, and air transportation. We are all supported.

1kg Coffee Beans Large Bag Checkweigher with Medium Speed Weight Checker

1. Equipment installation and debugging: The company provides detailed operation manuals and free operation training to enable customers to proficiently master the use of equipment.

2. Technical support: The company provides 7x24 hour technical support, and customers can contact engineers at any time to solve any problems encountered during use.

3. Accessory supply: The company provides original accessories to ensure the quality and stability of the accessories.

4. Quality assurance: The company is responsible for the products sold, ensuring that the quality and performance of the equipment meet industry standards.

5. One year warranty, lifetime maintenance
